SOORAN is an Unmanned Tele-Operated Combat Vehicle Mounted with Gun turret.
This can be operated in three Modes :
A Four Wheel Drive All-terrain Vehicle with 500 CC petrol Engine, Mounted with Turret, with provision to mount M249 Grade and above grade Equivalent guns.
Remotely operated from a Teleoperation Station using VSAT/4G network, a beautifully designed console with highly sophisticated software, the system feels a bit like a video game. Gunners can control the SOORAN using a Steering and joystick while watching the screens, which features a digital crosshair for aiming and a Dashboard with all necessary information required to drive a car.
SOORAN is equipped with Long Range cameras, high end processors, Sensors, power backup, built-in Generator and On board Computer. This advanced engineering of Vehicle and Tele-operation console enables to take down targets with high accuracy and precision.
Gunners can aim and control the SOORAN remotely sitting in a Tele-operation Console. The Gun Turret is capable of 360-degree rotation and −30 to +70 degree elevation and is gyro-stabilized.
The Tele-operated console still gives a panoramic front and rear view in a 23 inch display and a complete 360-degree view by traversing the turret.
The joystick and switches provide full control of weapon system with high accuracy.
Our Artificial Intelligence NIVATA plays a major role in providing Tracking capability, easily pick out targets, Image processing, shoot on the move capability, etc., and completely enables SOORAN to be stable on the targets even on rough terrains.
The NIVATA provides an option for autonomous operation to SOORAN with limitations to take up routine tasks, emergency engagements and border surveillance.
SOORAN being an intelligent war machine is going to be a breakthrough on improving the accuracy of how we fight.
No need to lose our Soldiers in protecting the borders. Not anymore.. Now our brothers fighting for us will safely be back home at the end of their deployment.
Vehicle Systems | ||
---|---|---|
Processors | : | JETSON Nano |
Controllers | : | Automative Controller for Servo Drive |
Communications | : | CAN |
Battery | : | Lithium Ion 48V |
Built-In Generator | : | 1KVA 750W Petrol |
Motors | : | Hybrid DC Servo |
Rugged Onboard Computer | : | I7, Rog Maximus X1 HERO, 2TB SSD, GT 710 NVIDIA |
Softwares | : | Python ML, Embedded C |
OS | : | Linux |
Teleoperation Station | ||
---|---|---|
Steering Wheel | : | Realistic 11"/28 cm wheel, embedded software Touch Sense technology |
Accelerator & Brake Pedal | : | Wide foot rest, Brake pedal with progressive resistance |
Joystick | : | 3 axis and 4 buttons plus I trigger for complete control, non-slip rubber pads for perfect stability |
Structure & Frame | : | Powder coated Metal fabricated, Sturdy and easy to assemble |
Monitors | : | 23 inch LED Screen |
Power Backup | : | I KVA 800W UPS |
System & Mother Board | : | 15-9600, Rog Maximus XI HERO, 2TB SSD, GT 710 NVIDIA |
Softwares | : | React JS, Python, Javascript, Mysql |
Server | : | Dedicated Server |
Other Accessories | : | Safety Key, Indicators, Maintenance rack, Keyboard, Mouse |
Seat | : | Adjustable Luxury driving seat |
Admin Panel | : | Secured Login, Reports, live recording, Map view, 56 Cross way reports |
Engine | ||
---|---|---|
Engine Type | : | Single Cylinder, 4-Stroke, 4-Valve |
Engine Displacement | : | 495 CC |
Fuel System | : | Electronic Fuel Injection |
Max Power Output | : | 38 HO @ 6800 RPM |
Cooling System | : | Liquid Cooled |
Transmission | : | Automatic |
Wheels, Suspensions and Brakes | ||
---|---|---|
Wheels | : | 12" Cast Aluminium Alloy |
Wheelbase | : | 50.7" |
Suspension | : | Double A-ARM Independent F/R |
Brakes | : | Hydraulic |
Dimensions and Weight | ||
---|---|---|
Length | : | 2100 MM |
Width | : | 1135 MM |
Height with turret | : | 1500 MM |
Height without turret | : | 935 MM |
Ground Clearance | : | 10.8" |
Weight Without Turret | : | 590 Kgs |
Turret | ||
---|---|---|
Tilt Axis | : | 360 Degree Rotation |
Pan | : | -30 to +70 degree elevation |
